Product Details:
Payment & Shipping Terms:
|
| Diameter: | 1200mm | Operating Speed: | 150 M/min |
|---|---|---|---|
| Mechanical Speed: | 170 M/min | Roller Surface Effective Width: | 1080mm |
| Control: | Mitsubishi PLC | Max Feeding Width: | 1000mm |
| High Light: | Label Inspection Machine,Cold Stamping Machine |
||
Tobacco Aluminum Automatic Foil Stamping Machine Backing Paper Coating Equipment
APPLICATION
Paperboard composite coating stripping machine is used for paper and aluminum foil or aluminum plating film back (printed), wet composite, painting (printing), stripping (online strip and strip), dry composite strip production, has the fixed length stretching, positioning printing function. It is elaborate designed with reference to paper or aluminum foil manufacturers of similar equipment at home and abroad , using multilayer baked road, reduce the space, waste lead head device to save raw material, making its produce qualitative leap in performance and reliability, product surface smooth, level off, without warping and buckling, no scratches, high speed and high efficiency. The whole machine all adopts ac frequency conversion motor and servo motor synchronous control, tension system controlled by floating roller, all adopt Taiwan or Japan touch screen as man-machine interface, with Japan's mitsubishi PLC as the core, has the high degree of automation.
MAIN TECHNICAL PARAMETERS
| Model | 1000 |
| Max feeding diameter(mm) | Paper Φ1200 Aluminum foil 450 |
| Max feeding width(mm) | 1000 |
| Roller surface effective width(mm) | 1080 |
| Mechanical speed(m/min) | 170 |
| The maximum operating speed(m/min) | 150 |
| Max rewindign diameter(mm) | 1200 |
| Dimension(mm) | 13600*2900*3933 |
