Product Details:
Payment & Shipping Terms:
|
| Paper: | Φ1600mm | Aluminum Foil: | Φ600mm |
|---|---|---|---|
| Film: | Φ600mm | Paper: | 80-300gsm |
| Aluminum: | 0.005-0.025mm | PET Film: | 0.012-0.025mm |
| High Light: | Post Press Machines,Cold Stamping Machine |
||
Paperboard Stripping Automatic Foil Stamping Machine Tobacco Packaging
APPLICATION
Paperboard composite coating stripping machine is used for paper and aluminum foil or aluminum plating film back (printed), wet composite, painting (printing), stripping (online strip and strip)and dry composite strip production. It has the fixed length stretching, positioning printing function, it is also elaborate designed with reference to paper or aluminum foil manufacturers of similar equipment at home and abroad , using multilayer baked road, reduce the space, waste lead head device to save raw material, making its produce qualitative leap in performance and reliability, product surface smooth, level off, without warping and buckling, no scratches, high speed, high efficiency, the whole machine all adopt ac frequency conversion motor and servo motor synchronous control, tension system controlled by floating roller. This all adopts Taiwan or Siemens touch screen as man-machine interface with Japan's mitsubishi or Germany's Siemens PLC as the core, has the high degree of automation.
MAIN TECHNICAL PARAMETERS
| Model | 800 | 1000 | 1200 |
| Max feeding width(mm) | 800 | 1000 | 1200 |
| Mechanical speed(m/min) | 170 | 170 | 170 |
| Roller surface effective width(mm) | 880 | 1080 | 1280 |
| Material | paper 80-300gsm | aluminum 0.005-0.025mm | PET film 0.012-0.025 mm |
| Max rewindign diameter(mm) | 1700 | 1700 | 1700 |
| Dimension(mm) | 24800*4300*4500 | 24800*4500*4500 | 24800*4700*4500 |
| Weight(KG) | 45000 | 50000 | 55000 |
