Siemens PLC Tobacco Packing Machine 180 Packets/Min 380 V 3 Phase

Item

Carton

1.Maximum Speed

18 Cartons/Min

2.Working Speed

18 Cartons/Min

3.PLC

Siemens

4.Text Display

HLP2

5.Technical Documents

English only

6.Ambient Temp

18-23℃

7.Ambient RH

50%-85% RH

8.Machine color

Green

9.Year two class preparation

According to user’s needs to order

10.Compressed Air Needs

pressure     >0.60Mpa
flow         >48m³/h
Used to convert the negative pressure

11.Diameter Supply Line

compress air ,  Inside diameter 8-10mm hose

12.Power

380 V, 3 Phase 60 HZ

13.Connected Load

1.5 KW

14.Safety Loop Voltage

24 V

15.Neutral wire required

Yes

16.Carton packing paper

1. white card board with neat edge, no printing ink on the joint part

2. dosage   260～300 g/ m²

3. tightness        ≥0.8 g/ cm³

4. The paper folded following the squeezed lines. When folds it vertically for three times, two planes of paper keep even without curve surface, the lines don't break after folding.

5. The direction of fiber in paper is vertical to the longer side

17.Condensation viscose

1.general requirement: strong adhesion, quick drying colorless, tasteless and poisonousless, no strip after drying

2.type white emulsion

3. viscosity      3.0～4.0 Pa.s

18.Carton Size

EuropeStyle  283×89×48.5mm
