Lamina Conditioning Cylinder Tobacco Processing Equipment 1 Year Warranty

WQ37A~WQ318B Series of Lamina Conditioning Cylinder

Application:

This product is used in tobacco primary processing line before cutting process for increasing temperature and
moisture of the lamina,which can improve the tenacity and processing durability of the lamina.In this way,
technological requirement for lamina cutting can be met.

Features:

- Frequency conversion speed regulation for the rotation of the cylinder.
- Rotary filtering screen with brush roller and hot water cleaning is set at upward side of material discharging
chamber.It is convenient to clean the rotary filtering screen.
- Auto control over casing application,temperature and moisture content.The parameters of running status,such
as flow rate of moisturized water,flow rate of casing liquid,hot air temperature,and rotary speed of cylinder,
etc.can be centralized monitored and controlled.
- Cylinder with auto jacking-up device for option,for purpose of convenient maintenance and reducing
compression against support roller during downtime.

Technical Specifications:

-Rated capacity:1600kg/h~9600kg/h
-Output temperature:40C~45C
-Increase of lamina moisture content:1%~3%(set as per users'requirements)
