Online Cigarette Production Machine Laser Perforation For Tipping Paper

Always give us professional suggestion, making our product winner in the market.

—— Johnny Baric

I like your product and service. You are my good partner and friend.

—— Mr.Sergey

Product is in high quality. promising after sales

—— Daniel

I'm Online Chat Now

Online Cigarette Production Machine Laser Perforation For Tipping Paper

Online Cigarette Production Machine Laser Perforation For Tipping Paper
Online Cigarette Production Machine Laser Perforation For Tipping Paper

Large Image :  Online Cigarette Production Machine Laser Perforation For Tipping Paper

Product Details:

Place of Origin: China
Brand Name: Upperbond

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Delivery Time: 30Works Dates
Detailed Product Description
Highlight:

cigarette packing machines

,

cigarette manufacturing equipment



High Speed Cigarette Production Machine Laser Perforation For Tipping Paper



Product Description

  1. This device has obtained many national practice new-type patents and has independent intellectual property rights.
  2. It has passed ISO9001 quality system certification.
  3. This device will not influence the function and efficiency of cigarette making machine.
  4. It utilizes the original interface and does not change the cigarette making machine’s structure.
  5. The optimized system does not to be maintained and operated by specific workers.
  6. High power laser generator - the whole system could meet the demands of cigarette
  7.  perforation in most kinds of high-speed cigarette making machines.
  8. A wide application range - PROTOS-70/80/90E/
  9. It’s easy and convenient to be operated with Chinese or English operating interface, it’s clear to set the parameter.



Production Configuration

  • Laser generator system - the CO2 radiofrequency pulse laser generator is imported from the USA.
  • Cigarette transferring device - cigarette hopper with low noise, highly precise cigarette drum and
  • unique drum driven mode.
  • Cigarette turning device - high frequency motor adjusts the speed and motor locating control.
  • Electric system and parameter display system - SIMENZ PLC and touch-screen provides man-machine interface, the lasers consisted of the most advanced Micro-control which control the main machine well.
  • Water colling system - the water temperature and water level system is composed by Sweden
  • GRUNDFOS pumps. There is a colling water inspection device in the laser generator.





Technical Parameter

Voltage

3x380 V AC, 50/60HZ

Power

≤ 6KW

Model of laser generator

CO2 pulse laser generator made in USA

Laser wavelength

10.6 um

Laser divergence amount

2.1 mrad

Laser diameter

7.2 mm

Punch pulse time

5-200 us

Holes number

0-99

Hole diameter

0.1-0.2 mm

Ventilation range

0-75% (adjustable)

Ventilation coefficient of variation

< 10%

Control precision

0.1 us

Single or Double rows of holes

(three rows could be optional)

Resonator’s life time

> 20,000 hours



Online Cigarette Production Machine Laser Perforation For Tipping Paper 0
