MK9,MAXS,HCF80 MAXSTobacco Making Machine

small.img.alt small.img.alt small.img.alt

Large Image :  MK9,MAXS,HCF80 MAXSTobacco Making Machine

Product Details:

Place of Origin: China
Brand Name: UPPER BOND
Model Number: MK9

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: WOODEN CASES
Delivery Time: 30Works Dates
Payment Terms: T/T
Supply Ability: 100 SETS/YEAR
Detailed Product Description
High Light:

cigarette packing machines


cigarette making equipment

Tobacco Making Machine MK9 Cigarette Maker And MAXS Plug Assembler
Ambient conditions:
Temperature: 20℃--30℃
Relative humidity: 62%--68%
2, Paper bobbin
Tensile strength ≥0.85KN/m
Extensibility >1.6%
Humidity: 6%±1.5%
Joint number <1/1000 m
3, Width: 48±0.3 mm
Thickness: 0.04mm~0.05 mm
4, Cut tobacco
Grade: A
Humidity: 12.5%±0.5%
5, 5.5bar
6, Viscosity of VPA
For the maker: 2500mPa.s-5000mPa.s
For the assembler: 5000mPa.s-10000mPa.s
Cigarette Making Machines with MK9 Maker, MAXS Plug Assembler
Cigarette maker  type:
  (a) MK9 cigarette maker
  (b)MAXS plug assembler
  (c)HCF80 tray filler
. Electric control system:
 ◆ control center: it adopts the SIEMENS PLC S7-300 series.
 ◆ weight controller: the microwave weight control system is adopted to avoid any harm to people.
 ◆ man-machine interface: The SIEMENS touch screen provides friendly man-machine interface, which displays the machine status and production data precisely. It is also convenient to modify the system parameter and check out the failure.
Main Parameters:
   It can be customized by producing king size cigarettes, super slim cigarettes or kreteks with different size. The weight  of the cigarette can be inspected and the bad cigarettes can be rejected online automatically. This type of combination has been sold to Asia, Africa, Europe and North America and also widely sold well all over the world .
1. The cigarette cutting system uses the double-knife single-cutting system with lower-rise temperature and lower noise. This gives the very good quality of the cigarette cut.
 2. The hopper system adopts AC servo motor to directly drive the tobacco cutting system. The timing belts are used instead of the gears, so the even tobacco-feeding is greatly improved and the maintenance cost is reduced as well.
 3. It adopts AC servo driving system that simplifies the mechanical structures and reduces the failure and maintenance cost, and improves the transmission precision.
 4. The complete suction system and high air pressure system .
Main Parameter:

Output: 5000cig/min for the king size cigarettes

Frequency: 50Hz

3500cig/min for the super slim cigarettes

Total power: 50KVA

Cigarette parameter

Outside dimensions

Filter-cigarette length: 65 ~110± 0.5 mm

Cigarette maker : 3630× 1270 × 1870mm

Tobacco rod length: 55 ~90 mm

Plug assembler: 3340×1340× 1820mm

Cigarette diameter: φ 5.4 ~φ 9.0 mm

Tray Filler : 2350×2400× 2100mm

Power supply: 380V ± 10%(3phases)

Total weight: 8600kg

MK9 Maker, MAXS Plug Assembler, HCF80 tray filler cigarette maker
MK9,MAXS,HCF80 MAXSTobacco Making Machine 0
MK9,MAXS,HCF80 MAXSTobacco Making Machine 1
