110V 60Hz , 220V 50Hz Laser Perforation Machine Cigarettes And Filter Rod Test Station
Cigarettes And Filter Rod Multifunction Test Station series
Summary:
l Using Windows XP Embedded operating system;
l Built-in Industrial PC;
l Using high-precision sensor;
l Automated testing, fast measurement;
l Possess the fault diagnosis and self-checking function;
l Simultaneous measurement of multiple items;
l 10.4-inch TFT color LCD screen or 12.1-inch Industrial Panel PC plug-in type, friendly interface, easy to grasp;
l Rugged design;
l Modular design, each module relative antagonistic;
l Data interface: parallel portserial interfaceEthernet interfaceUSBKeyboard and mouse interface;
l Low cost of ownership.
l Sample circumference range: 21 ~ 28mm
l Sample length range: 80 ~ 150mm
l Capacity of sample incoming system : ≥50P
l With printing
Requirements:
l POWER Supply: 110 volts/60Hz or 220 volts/50Hz. Please state voltage and frequency requirements at time of order.
Compressed air: 5 bar, oil free.
MTS Cigarette/Filter Rod Multifunction Test Station
Specifications:
|
Test Project |
Range |
Resolution |
Accuracy |
|
Weight |
0～200g |
0.001g |
±0.001g |
|
Circumference |
21～28mm |
0.005mm |
±0.01mm |
|
Length |
80～150mm |
0.005mm |
±0.05mm |
|
Draw Resistance |
0～8000Pa |
10Pa |
1.0% F.S.D |
|
Ventilation Ratio |
0～100% |
0.1% |
±1.0% |
|
Hardness |
Pressure:2.94N±0.01N Pressing time: 15s±1s Resolution: 0.001mm |
±0.5% |
|
