Automatic Fibre Filter Rod Forming Machine , Commercial Cigarette Making Machine

China Automatic Fibre Filter Rod Forming Machine  , Commercial Cigarette Making Machine supplier

Large Image :  Automatic Fibre Filter Rod Forming Machine , Commercial Cigarette Making Machine

Product Details:

Place of Origin: China
Brand Name: Upperbond

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: 30Works Dates
Payment Terms: T/T, L/C
Supply Ability: 200 sets per year
Contact Now
Detailed Product Description
ZL23 Unit:: YC/T113-1996 Vinegar Fiber Filter Rod:: GB/T 5605-2002
Unit Weight:: 3500Kg Compressedair:: Flow≥1.5m3/min, Kpa≥0.5MPa
Devilation From Circular Form: ≤0.35mm Circle Of Filter Rod:: 24.0~24.5mm±0.20

Automatic Fibre Filter Rod Forming Machine  , Commercial Cigarette Making Machine





Opener applied with three-level air opening,two-level thread roller opening to completely stretch,loose, spread and gluing uniformity, and the forming machine take high-precision spiral bevel gear and paralleling  short shaft driving, single tool rod cutting, to make sure filter rod’s length has small error. Opium pipe use  unitary and hot melt adhesive side sealing, making it easy for adjustment and operation, and reliable for

splicing. The rod cutting blade applied with automatically cut feeding,automatically sharpen, to make the filter rod

notch  smooth and flattening.



ZL23 set of unit applied with PLC control, frequency conversion, automatically adapting paper, with

complete  functions and high degree of automation, all kinds of parameter digitization demonstrated, easy

for operation, and wide scope for raw material, it is the perfect medium speed filter rod forming equipment.





Technical parameter

Product capability

250m/min(vinegar fiber) 160m/min(C fiber)

Length of filter rod :

80-144mm±0.5

Circle of filter rod:

24.0~24.5mm±0.20

Devilation from circular form:

≤0.35mm

Unit power:

22KW

Compressedair:

flow≥1.5m3/min, Kpa≥0.5MPa

Unit weight:

3500Kg







Executive standard:

ZL23 unit:

YC/T113-1996

Vinegar fiber filter rod:

GB/T 5605-2002

C fiber filter rod:





Automatic Fibre Filter Rod Forming Machine  , Commercial Cigarette Making Machine
