Automatic Cigarette Making Machines 90 Mm Tobacco Rod Length With MK9 Maker

large.img.alt
small.img.alt

Large Image :  Automatic Cigarette Making Machines 90 Mm Tobacco Rod Length With MK9 Maker

Product Details:

Place of Origin: China
Brand Name: UPPER BOND
Model Number: MK9

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: WOODEN CASES
Delivery Time: 30Works Dates
Payment Terms: T/T, L/C
Supply Ability: 100 SETS/YEAR
Detailed Product Description
Output: 5000cig/min Control Center: SIEMENS PLC S7-300 Series
Color: Green Cigarette Size: King Size,Slim Size,Super Slim Size
Tray Filler :: 2350×2400× 2100mm Total Weight: 8600kg
High Light:

cigarette packing line

,

cigarette packaging machine

Automatic Cigarette Making Machines 90 Mm Tobacco Rod Length With MK9 Maker





Highlights:



1. It adopts AC servo driving system that simplifies the mechanical structures and reduces the failure and maintenance cost, and improves the transmission precision.

2. The complete suction system and high air pressure system .

 3. Man-machine interface: The SIEMENS touch screen provides friendly man-machine interface, which displays the machine status and production data precisely. It is also convenient to modify the system parameter and check out the failure.

 4. The cigarette cutting system uses the double-knife single-cutting system with lower-rise temperature and lower noise. This gives the very good quality of the cigarette cut.

 5.  The timing belts are used instead of the gears, so the even tobacco-feeding is greatly improved and the maintenance cost is reduced as well.





 Main Parameters:



Output: 5000cig/min for the king size cigarettes

Frequency: 50Hz

3500cig/min for the super slim cigarettes

Total power: 50KVA

Cigarette parameter

Outside dimensions

Filter-cigarette length: 65 ~110± 0.5 mm

Cigarette maker : 3630× 1270 × 1870mm

Tobacco rod length: 55 ~90 mm

Plug assembler: 3340×1340× 1820mm

Cigarette diameter: φ 5.4 ~φ 9.0 mm

Tray Filler : 2350×2400× 2100mm

Power supply: 380V ± 10%(3phases)

Total weight: 8600kg





 Making Process Requirements:


1, Ambient conditions

Temperature: 20℃--30℃

Relative humidity: 62%--68%

2, Paper bobbin

Tensile strength ≥0.85KN/m

Extensibility >1.6%

Humidity: 6%±1.5%

Joint number <1/1000 m

3, Width: 48±0.3 mm

Thickness: 0.04mm~0.05 mm

4, Cut tobacco

Grade: A

Humidity: 12.5%±0.5%

5, 5.5bar

6, Viscosity of VPA

For the maker: 2500mPa.s-5000mPa.s

For the assembler: 5000mPa.s-10000mPa.s



Automatic Cigarette Making Machines 90 Mm Tobacco Rod Length With MK9 Maker 0
