Green High Speed Cigarette Making Machines With Filter Assembling And Tray Filler

China Green High Speed Cigarette Making Machines With Filter Assembling And Tray Filler supplier

Large Image :  Green High Speed Cigarette Making Machines With Filter Assembling And Tray Filler

Product Details:

Place of Origin: China
Brand Name: UPPER BOND
Model Number: MK9

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: WOODEN CASES
Delivery Time: 30Works Dates
Payment Terms: T/T, L/C
Supply Ability: 100 SETS/YEAR
Contact Now
Detailed Product Description
Output: 5000cig/min Control Center: It Adopts The SIEMENS PLC S7-300 Series.
Color: Green Cigarette Size: King Size,Slim Size,Super Slim Size
Temperature: 20℃--30℃ Tensile Strength: ≥0.85KN/m

Green High Speed Cigarette Making Machines With Filter Assembling And Tray Filler





This combination consists of three machines: MK9 cigarette maker, MAXS plug assembler and HCF80 tray filler.





Highlights:



1. The cigarette cutting system uses the double-knife single-cutting system with lower-rise temperature and lower noise. This gives the very good quality of the cigarette cut.

2. The complete suction system and high air pressure system .

3. The hopper system adopts AC servo motor to directly drive the tobacco cutting system. The timing belts are used instead of the gears, so the even tobacco-feeding is greatly improved and the maintenance cost is reduced as well.

4. It adopts AC servo driving system that simplifies the mechanical structures and reduces the failure and maintenance cost, and improves the transmission precision.

5. control center: it adopts the SIEMENS PLC S7-300 series.





 Making Process Requirements:


1, Ambient conditions

Temperature: 20℃--30℃

Relative humidity: 62%--68%

2, Paper bobbin

Tensile strength ≥0.85KN/m

Extensibility >1.6%

Humidity: 6%±1.5%

Joint number <1/1000 m

3, Width: 48±0.3 mm

Thickness: 0.04mm~0.05 mm

4, Cut tobacco

Grade: A

Humidity: 12.5%±0.5%

5, 5.5bar

6, Viscosity of VPA

For the maker: 2500mPa.s-5000mPa.s

For the assembler: 5000mPa.s-10000mPa.s





 Main Parameters:



Output: 5000cig/min for the king size cigarettes

Frequency: 50Hz

3500cig/min for the super slim cigarettes

Total power: 50KVA

Cigarette parameter

Outside dimensions

Filter-cigarette length: 65 ~110± 0.5 mm

Cigarette maker : 3630× 1270 × 1870mm

Tobacco rod length: 55 ~90 mm

Plug assembler: 3340×1340× 1820mm

Cigarette diameter: φ 5.4 ~φ 9.0 mm

Tray Filler : 2350×2400× 2100mm

Power supply: 380V ± 10%(3phases)

Total weight: 8600kg



Green High Speed Cigarette Making Machines With Filter Assembling And Tray Filler
