Soft Pack Cigarette Production Machine X1SC / 4350 / PACK-OW

China Soft Pack Cigarette Production Machine X1SC / 4350 / PACK-OW supplier

Large Image :  Soft Pack Cigarette Production Machine X1SC / 4350 / PACK-OW

Product Details:

Place of Origin: China
Brand Name: UPPER BOND
Model Number: GDX1

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: w
Delivery Time: 30Works Dates
Payment Terms: T/T
Supply Ability: 100 SETS/YEAR
Contact Now
Detailed Product Description





Soft Pack Cigarette Production Machine X1SC / 4350 / PACK-OW





Product Information:



GDX1-CH cigarette packing machine for soft pack is also a medium-speed model, capable of producing 400 soft packets per minute. It was developed on the basis of X1SC/4350/PACK-OW, which technology was introduced through the Technology Transfer Agreement between G.D, and China National Tobacco Corp. It consists of an YB15 Tray Feeder, an YB25 Cigarette Soft Packer, an YB55 Cellophaner, an YB65 Cartoner and an YB95 Overwrapper.





Features:


The entire working process, from cigarettes feeding to carton overwrapping, is completed automatically without any manual contact. The settings of machine operation, quality control, shift reporting, enhanced stoppage analysis, machine status, diagnostics and system calibration are achieved entirely digitally by the  brand new MICRO-II system with integrated touch screens.

GDX1-CH won the third prize at the Technology and Improvement Competition by State Tobacco Monopoly Bureau in 1998.





Technical Data:



Production Capacity:

400 packets/min (40 cartons/min)

Cigarette Specifications



Diameter:

φ7.8mm

Length:

84mm

Cigarette Collation:

7-6-7

Packet Dimension:

86mm ×54.5mm ×22.5mm

Stamp Specifications



Width:

19mm ~23mm

Length:

42mm~50mm

Carton Dimension:

274mm × 87.5mm × 46.5mm

(American and European style)

Noise Level:

≤85 dB(A)

Power:

19.1kw

Weight:

9370kg

Floor Area:

7300mm × 7600mm

(All the products specification can be configured upon customized requirements.)
