Automatic 47KVA 7000cig / min Cigarette Making Machines with trouble- shooting system

Always give us professional suggestion, making our product winner in the market.

—— Johnny Baric

I like your product and service. You are my good partner and friend.

—— Mr.Sergey

Product is in high quality. promising after sales

—— Daniel

I'm Online Chat Now

Automatic 47KVA 7000cig / min Cigarette Making Machines with trouble- shooting system

large.img.alt
small.img.alt

Large Image :  Automatic 47KVA 7000cig / min Cigarette Making Machines with trouble- shooting system

Product Details:

Place of Origin: China
Brand Name: UPPER BOND
Model Number: PROTOS 70-CH

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: WOODEN CASES
Delivery Time: 30Works Dates
Payment Terms: T/T
Supply Ability: 100 SETS/YEAR
Detailed Product Description
High Light:

cigarette packing line

,

cigarette packaging machine

,

7000cig/min Cigarette Making Machines



Automatic 47KVA 7000cig / min Cigarette Making Machines with trouble- shooting system



High speed Cigarette Making Machines 47KVA 7000cig/min





Product  Information:


PROTOS 70-CH Cigarette Making and Filter Assembling Group consists of Model PROTOS 70-CH Cigarette Making Machine and Filter Assembling Machine. Its downstream device can be Tray Filler or linkage equipment to packer, with the features below:



1.High speed: the production speed of cigarette can reach 7000cig/min, rod speed is 490m/min.

2. Top quality of cigarette : it performs the functions of inspecting air leakage,  loose ends, soft and hard spots and rejecting the unqualified cigarettes automatically.

3. Complete trouble- shooting system: it has the effects of diagnosis, alarm, displaying the faults then stop, analyzing and adding up the faults automatically.

4. Perfect control system for cigarette weight: it can offset automatically and save cut tobacco by use of target weight.

5.Automatic production process system: it has the functions of monitoring, analysis , statistics, handling to the processing datum and outputting in forms automatically.





Main Parameters:




Rod speed

490m/min

Production Capacity

7000cig./min

Cigarette Circumference

21.7mm-28.3mm

Cigarette Length

65mm-120mm

Filter Rod Length

10mm-25mm(1rod/6) 15mm-35mm(1rod/4)

Total Power

47KVA

Dimension(L× W× H)

6740mm×6030mm×2600mm(U)

Total Weight

10080kg



Automatic 47KVA 7000cig / min Cigarette Making Machines with trouble- shooting system 0
