0.35mm ZL23 Cigarette Filter Machine Precision With Intermediate Speed

Always give us professional suggestion, making our product winner in the market.

—— Johnny Baric

I like your product and service. You are my good partner and friend.

—— Mr.Sergey

Product is in high quality. promising after sales

—— Daniel

I'm Online Chat Now

0.35mm ZL23 Cigarette Filter Machine Precision With Intermediate Speed

large.img.alt
small.img.alt

Large Image :  0.35mm ZL23 Cigarette Filter Machine Precision With Intermediate Speed

Product Details:

Place of Origin: China
Brand Name: Upperbond

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: 30Works Dates
Payment Terms: T/T, L/C
Supply Ability: 200 sets per year
Detailed Product Description
Color: White Speed: 250m/min
Brand: Upperbond Circle Of Filter Rod:: 24.0~24.5mm±0.20
Compressedair:: Flow≥1.5m3/min, Kpa≥0.5MPa Application:: Cigarette,
High Light:

industrial cigarette rolling machine

,

commercial cigarette making machine

,

fiber filter rod forming machine

0.35mm ZL23 Cigarette Filter Machine Precision With Intermediate Speed





ZL23 set of fiber filter rod forming machine consists of YL13 loose gluing machine andYL23 filter rod forming machine. It takes cellulose acetate tows or polypropylene tows as raw material, after air loosing,thread loosing,gluing,involution,sideseal,forming and cutting, formed equilong filter tipping rod which meet the high-speed adapter request.



The machine can also use acetate tow and C tow.



Opener applied with three-level air opening,two-level thread roller opening to completely stretch,loose,spread and gluing uniformity, and the forming machine take high-precision spiral bevel gear and paralleling short shaft driving, single tool rod cutting, to make sure small error of filter rod length. Opium pipe uses unitary and hot melt adhesive side sealing, making it easy for adjustment and operation, and reliable for splicing. The rod cutting blade applied with automatically cut feeding and automatically sharpen makes the filter rod notch smooth and flattening.




Parameters:



Technical parameter

Product capability

250m/min(vinegar fiber) 160m/min(C fiber)

Length of filter rod :

80-144mm±0.5

Circle of filter rod:

24.0~24.5mm±0.20

Devilation from circular form:

≤0.35mm

Unit power:

22KW

Compressedair:

flow≥1.5m3/min, Kpa≥0.5MPa

Unit weight:

3500Kg







0.35mm ZL23 Cigarette Filter Machine Precision With Intermediate Speed 0
