MC50 4pcs Blade Mini Tobacco Cutting Machines With High Quality

China MC50 4pcs Blade Mini Tobacco Cutting Machines With High Quality supplier

Large Image :  MC50 4pcs Blade Mini Tobacco Cutting Machines With High Quality

Product Details:

Place of Origin: CHINA
Brand Name: UPPER BOND
Model Number: MC50

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Packaging Details: WOODEN CASES
Payment Terms: T/T
Detailed Product Description
Rated Capacity: 200-500kg/h



MC50 4pcs Blade Mini Tobacco Cutting Machines With High Quality

Description

 MC50 Mini Cutter is the new product that our company independently developed. It combines the character and actual production experience of the similar type, with high performance, high technical content of roller knife type Mini Cutter, aiming at meet the need of the small production and laboratory actual requirement.

1.  Main purpose and scope

MC50 Mini Cutter applies to cut lamina/stem with the speed of 200-500kg/h in the pilot line or lab. To make the specification of the processed lamina and stem conforms to the specified requirements of the cigarette craft. The width of cutting is adjustable at the range of 0.1-3mm easily.

MC50 Mini Cutter also applies to the vegetables cutting and processing in the food processing production line with the speed of 500-1500kg/h. To make the specification of the processed vegetable leaves conforms to the specified requirements of the craft. The width of cutting is adjustable at the range of 0.1-6mm easily.



This cutter is wide scope, easy to use and maintain, with advanced control function for cutting width, speed, material status, fault display, manual and automatic control functions.




2.  Basic parameter and main performance indexes


Item

Unit

MC50-I

MC50-IB

Remarks

1  Cutting width

mm

0.4-2

0.1-0.4



2  Rated capacity

kg/h

50-500

20-100



3  Knife door high

mm

5-20

5-20



4  Knife door width

mm

200

200



5  Blade quantity

pcs

4

4



6  Knife roll rate

rpm

100-400

100-400



7  Supply gas pressure

mpa

0.6





8  Total power

kw

4.61





9  Weight

kg/h

500





10       Overall dimension

mm

1160*577*1077







3.  Operating conditions:


a) Relative humidity: ≤80%

b) Ambient temperature: 10~40℃

c) Sea level elevation: ≤2000m

d) Power: 3N~50HZ, 380V±38V;50HZ±1HZ

e)Compressed air: Pressure ≥0.3MPa  Flow≥0.2m3/min, after dry and filtration

f)Feeding:

Tobacco: Stem conforms to the 5.5.2 regulations of the , comply with the leaf conforms to the 6.2.2 regulations of the .

g) Metal flush trimmer should be set at the Feed End.

h) Operators shall take professional training, and can be practically operate the machine according to the requirement standardized of the instruction.





Specifications:
1.Good control performance,highly automation.
2. Simple Structure.
3.Easily operate.
4.Easy to use, maintain and manage.
