Metallic Material Tobacco Processing Machinery Snus Smoke Free Three - phase 380V

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Metallic Material Tobacco Processing Machinery Snus Smoke Free Three - phase 380V

Product Details:

Place of Origin: CHINA
Brand Name: UPPERBOND
Certification: CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wooden case
Delivery Time: 60 Works Dates
Supply Ability: 1000sets/year
Detailed Product Description
Condition: New Color: Metallic
Voltage: 380v Port: Guangzhou
Material: Metallic Production Capacity: 180pac/min
High Light:

tobacco packing machine

,

molasses machine





Mouth Smoking Cigarette Tobacco Production Equipment



Introduction :



Mouth smoking cigarettes, also known as Snus, smoke free cigarettes, is a new variety of tobacco products.



It's a smokeless tobacco, so It does not produce smoke, it is much more healthier than cigarettes, and it does not affect others, also not subject to smoking restrictions, so it is an ideal substitute for cigarettes.



Production line included:



1.Material pulverizer

The pulverizer makes use of the relative motion between the movable tooth disk and the fixed tooth disk to crush the material through tooth impact, friction and impact between the materials



Specification:



Supply voltage:



Three-phase 380V



Power consumption:



4KW



Production capacity:



20-40Kg/h



Particle fineness:



20~60 mesh



Spindle speed:



2800r/min



Overall dimension:



500×600×1450mm





2.Three-stage disk vibrating screen

The vibrator of the screen drives the vibrating screen together to perform the directional jumping movement. The material smaller than the aperture of the screen surface falls to the lower layer through the screen hole and becomes the material under the screen. The material larger than the aperture of the screen surface is discharged from the discharge port after continuous jumping movement.

Different diameters of screen particles are obtained by using different diameters of screen hole .



Specification:

Supply voltage



three-phase 380V



Power consumption



0.25KW



Nominal Diameter



φ600mm



Screening series



Three-stage(optional 20/40/60)



Vibration times



1450 rpm

Overall dimension



1800×1450×1200mm





3.material mixing and preloading equipment

Manually add weighied materials. The stirring motor drives the mixier shaft for material mixing. Various ingredients are added into the batching tank through metering pump for metering and feeding, ultilizing the high pressure air to increase the atomization of the feed liquid, so that the ingredients can be evenly sprayed on the surface of the material while stirring. The way of discharging is manually rotate the handwheel to make the material box discharge material. And if the material discharge is not completely, manual assistance discharge is necessary.



Specification:



Supply Voltage



three-phase 380V



Equipment Power



0.9KW



Nominal Capacity



50L



Stirring Rate



0~50r/min



Tank volume



2.5L (2, according to the needs)



Overall Dimension



1100×700×1500mm





4.Horizontal Fermenter

Horizontal double spiral mixing, can efficiently and fully mix the material.

The new tank bottom valve, no dead ends, complete discharge.

With independent steam generator and cooling device, cooling speed is fast. Reduce the cost of the heat conduction oil.

Large size manhole device for easy cleaning and cleaning of tanks



Specification:



Supply Voltage



three-phase 380V



Equipment Power



60KW (steam plus 50KW)



Nominal Capacity



1600L (Processing capacity 150Kg/batch)



Stirring Rate



5~60r/min



Operation pressure

1.2~1.5Bar (according to the needs)



Overall Dimension



2600×1400×2900mm



Air pressure



4Bar





5. Snus high speed packing machine

High speed, stable operation at 180 pack.

Four sets of servo system drive, with electronic gear instead of the traditional mechanical transmission chain.

The feeding device is added to the material bin to reduce the workload of the people.

The new transverse seal cutting structure design makes the sealing more beautiful.

Double side sawtooth cutter, high speed pneumatic drive to ensure complete cutting.



Specification:



Supply Voltage



three-phase 380V



Equipment Power



4.5KW



Production capacity



180pac/min(according to the product)



Specification



32×13×5mm (0.3 g/per)



Packing Film



Non-woven fabric (high permeability)



Overall Dimension



1700×1100×2000mm



Material moisture



≤35%





6.Snus secondary packing machine

In order to ensure the health safety and long-term storage requirements of mouth smoking cigarettes, a composite film was added to the outer packaging of the mouth smoking cigarettes to reduce the influence of external factors such as air, sunlight and so on.



Various of color patterns are made on the outer surface of the composite film, which enhances the attraction of the product.



Specification:



Supply Voltage



Single-phase 220v



Equipment Power

6.5KW



Production capacity



40pac/min (according to product)



Specification



51×22×6mm



Packing Film



Thickness ≤0.05mm (heat sealing film)



Overall Dimension



4500×1200×1650mm



Material moisture



≤30%
